PNEUMATIC LINEAR ACTUATORS
Technical data
Type:
Double-acting pneumatic linear cylinder
Piston diameter:
Ø 100
Ø 125
Ø 160
Ø 200
Ø 250
Ø 320
Stroke range: SC:
90 mm to 1030 mm The SC linear cylinder series
comprises 6 sizes.
Max. permissible control pressure: Capacity range: 4712 N– 48255 N
10 bar with a control pressure of 6 bar.
Temperature range:
-30 °C to +100 °C (standard)
High and low temperature
version on request
Capacity range:
4712 N– 48255 N (6 bar)
Control valve mounting:
Namur, VDI / VDE 3845
Control medium:
Filtered, dry compressed air
acc. to ISO 8573-1:2010
min. Class 3
Other control media on request
Namur interface Position feedback
Cylinder:
Housing: anodised aluminium
Cover: powder-coated
The NAMUR interface for direct mounting of Integrated keyway in the housing for mounting
control valves and the air ducts integrated into the limit switches in accordance with ISO 15552 for
housing reduce the mounting and tubing required non-contact position detection.
to a minimum.
